Street reflector

Street light in best form

For us, road traffic safety begins with lighting. Besides delivering 20 percent more brilliant light to the street, Auer Lighting's reflector also attracts attention with its extraordinary and compact design. Our reflector made of SUPRAX® 8488 borosilicate glass is the result of remarkable optical developments using freeform surfaces with facets. Together with our highly reflective PICVD coating, we are setting new standards in street lighting.

Street S3 (EU)

  • Pole height: 8 m
  • Street width: 7 m
  • Overhang: -1 m
  • Distance Pole to Pole: 44 m
  • Min/Max/Mean: 3/31/12 lux with 90W
  • Reflector size: 130 x 100 x 103 mm
  • Weight:  200g
  • Dichroic antifrost coating
  • Wattages: 90W, 140W
  • Color temperatures: 2800K, 4000K
  • Color Rendering Index: 70
  • Reference light engine available

Street Type II (US)

  • Pole height: 11 m
  • Street width: 12 m
  • Overhang: 2 m
  • Distance pole to pole: 36 m
  • Min/Max/Mean: 18/40/30 lux with 210W
  • Min/Max/Mean: 27/64/46 lux with 315W
  • Reflector size: 221x 165 x 91 mm
  • Weight:  400g
  • Dichroic antifrost coating
  • Wattages: 210W, 315W
  • Color temperatures: 3100K und 4200K
  • Color Rendering Index: 90
